Specifications | |
---|---|
Input | 210–240 V AC 50/60 Hz |
Starting | 45 KV starting pulse |
Power rating | 800–1200 watts (adjustable)—recommended 800–1000 watts |
Lamp module type | 1000 watt Xenon, 1000 watt Mercury/Xenon (proprietary to HORIBA) |
Lamp life | Typically 1,500 hrs |
Focusing optics | High efficiency f/4 ellipsoid reflector |
Power precision | 0.04% (0.4 watts) |
Output volts compliance | 17–23 VDC |
Output current limit | 70 A rms |
Window diameter | 127 mm (5.0 inches) |
Central beam light height (without feet) | 128 mm (5.0 inches) |
Spot size | 8 mm FWHM |
Optical power | 100 watts broadband |
Optical stability | 2% |
Optical noise (ripple) | From 0.15% to 0.2% RMS |
Dimensions (LxWxH) | 489 mm (19.3 inches) x 375 mm (14.8 inches) x 329 mm (12.9 inches) |
Weight | 31 kg (68 pounds) |
